KS20 -13PL Solvent Banner Printing Machine

KS20 -13PL Banner Printing Machine

The latest Kaliedo KS20-13PL banner printing machine for brilliant, durable, high-quality prints. Ideal for business, sign shops, and large-format needs, our series is at the top of the game in terms of precision, speed, and efficiency. Advanced technology and hassle-free operation are the key features.

** VIEW AND DOWNLOAD THE BROCHURE **

Get Pricing Download Brochure

The Kaleido KS-20 (13PL) is one of the most environment-friendly solvent printers using the Greentech printing technology of KDS. It's designed to offer sustainability via mild-solvent inks that significantly reduce chemical emissions, which translates to reduced environmental and health hazards. This solution balances efficiency, quality, and eco-consciousness at its core, offering responsible business benefits without sacrificing performance.".

Model - KS20
Technical Key Specification
Print Heads		Japanese Konica Minolta Head KM1024i (13pL)
		KS-2045		KS-2085
		4 Head		8 Head
Media	Width	3300mm (129 in)
	Thickness	Maximum 3.0 mm (120 mil) with Liner (flexible)
	Roll Outer Diameter	Maximum 352 mm (14.08 inch) 50.8 (2 in)
	Roll Weight	Maximum 150 kg
	Core Diameter	76.2 mm (3 in)
Media Types		Vinyl, Flex, PVC Banner, Polyster Fabric,Backlite Film, Fabric (Solvent Base)
Media Heating System		Pre-heater and post-heater, setting range for the preset temprature-30 to 600c Dryer setting range for the preset temprature: 30 to 600c
Print Specifications
Printing Width		Maximum 3200mm (126 inch)
Connectivity		High-Speed USB
Printing Resolution (dots per inch)		Maximum up to 1440 dpi
Ink Specifications
Ink Types		Solvent Ink
Ink Colors		CYAN, MAGENTA, YELLOW, BLACK (CMYK) (4 Color)
Power Consumptions & Working Environment
Power Requirements		AC 220V +/-10% 20 Amps, 50/60 Hz
Power ON		Temperature 18 to 280C Humidity: 20 to 80%RH (non-condensing)
Power OFF		Temperature 5 to 400C Humidity: 20 to 80%RH (non-condensing)
Machine Measurements
Printer Dimensions		4955mm x 945mm x 1575mm (LxWxH)
Weight (approx with stand)		1500 Kgs
Performance
Print Mode	Print DPI	Passes	Speed - 4 Head	Speed - 8 Head
Mode 1	540x720	2P	1175 SQFT/HR	2056 SQFT/HR
Mode 2	540x1080	3P	785 SQFT/HR	1374 SQFT/HR
Mode 3	540x1440	4P	495 SQFT/HR	866 SQFT/HR
Mode 4	540x1080	6P	410 SQFT/HR	718 SQFT/HR
Mode 5	540x1440	8P	280 SQFT/HR	490 SQFT/HR
